The Notch series of regressed downlights is characterized by a deep-set LED position which greatly reduces glare, neatly packaged in a price-conscious solution to general lighting.
Standard Information
Category:
Recessed Ltg.
Subcategory:
Recessed Lighting Accessories
Finish:
White
Option:
Energy Star
Title 24
Outdoor
Wet Rated
Voltage:
100-120
Lumens:
450-800
Kelvin:
2501-3000
Location Rating:
Wet Rated
Refinement Options
Category:
Recessed
Subcategory:
Regressed
Finish:
White
Family:
Notch
Voltage:
120 V
Number of Bulbs:
1 Bulbs
Bulb Dimmable:
Yes
Bulb Hours:
50000
Kelvin:
2700, 3000, 3500, 4000, 5000
Material:
Aluminum
Ship Carton Height:
3.7
Ship Carton Length:
5.6
Ship Carton Width:
5.5
Warranty:
5 Years Limited
Weight:
1
Air-Tight (ASTM E283--4):
Yes
Beam Angle:
100°
Bulb CRI:
90
Country of Origin:
China
Delivered Lumens:
800
Dimmer Type:
Triac
Energy Star:
Yes
IC Certification:
Yes
Indoor:
Yes
IP Rating:
IP44
JA8:
Yes
Lens Material:
Acrylic
Location Rating:
Wet Rated
Max Wattage:
11 W
Maximum Working Temperature:
40°C
Minimum Working Temperature:
-20°C
Outdoor:
Yes
Safety Rating:
ETL Approved
Shipping Master Height:
16
Shipping Master Length:
17.13
Shipping Master Quantity:
24
Shipping Master Weight:
28
Shipping Master Width:
12
Title 24:
Yes
Wiring:
Hardwired
Edge lit technology
Frosted lens
Over 50,000 hours of service life
Smooth 360 degree wide spread
Switch-selectable CCT: 2700 K/3000 K/3500 K/4000 K/5000 K
![4'' 5CCT 1" deep regressed panel](/vendors/776/large/drr4-cc-wh-scaled-1_01.jpg "4'' 5CCT 1" deep regressed panel")
